DIYables Mini MP3 Player Module for Arduino, ESP32, ESP8266, Raspberry Pi - Compact Audio Playback for DIY Projects
Click to zoom
Quick Overview
The DIYables mini MP3 player module provides compact audio playback for embedded projects. It plays MP3 files stored on a microSD/TF card (up to 32GB) and communicates via UART serial interface, making it simple to integrate with microcontrollers.
This 2-pack includes two MP3 player modules ideal for robotics, IoT audio applications, voice prompts, sound effects, and DIY electronics. The modules support multiple control modes including onboard button, serial commands, and AD key control. They work with Arduino, ESP32, ESP8266, Raspberry Pi, and other microcontrollers.
Key Features
- Compact Size — Small form factor for space-limited projects
- TF Card Support — Compatible with microSD/TF cards up to 32GB
- UART Serial Communication — Simple serial interface for microcontroller control
- Multiple Control Modes — Supports onboard button, serial, and AD key control
- 2-Pack — Includes two modules for multiple projects or backup
- Easy Integration — Beginner-friendly for DIY electronics and robotics
- Tutorial Support — Comprehensive tutorials for Arduino, ESP32, ESP8266, and Raspberry Pi
SPECIFICATION
| Specification | Value |
|---|---|
| Product Type | Mini MP3 Player Module |
| Communication | UART serial interface |
| Storage Support | MicroSD/TF card up to 32GB |
| Control Modes | Onboard button, Serial commands, AD key control |
| Audio Format | MP3 |
| Operating Voltage | 3.2V - 5V DC |
| Output | Speaker terminals and 3.5mm audio jack |
| Baud Rate | 9600 bps (default) |
| Dimensions | Compact mini module |
| Package Quantity | 2 pieces |
Tutorials
- Arduino - Mini Mp3 Player Module
- Arduino Uno R4 - Mini Mp3 Player Module
- Arduino Nano - Mini Mp3 Player Module
- Arduino Nano ESP32 - Mini Mp3 Player Module
- Arduino Nano 33 IoT - Mini Mp3 Player Module
- Arduino MKR WiFi 1010 - Mini Mp3 Player Module
- Arduino Mega - Mini Mp3 Player Module
- Arduino Giga R1 WiFi - Mini Mp3 Player Module
- ESP32 - Mini Mp3 Player Module
- ESP32 MicroPython - Mini Mp3 Player Module
- ESP8266 - Mini Mp3 Player Module
- Raspberry Pi Pico - Mini Mp3 Player Module
COMPATIBLE HARDWARE
- Arduino boards (UNO, Mega, Nano, etc.)
- ESP32 development boards
- ESP8266 (NodeMCU, Wemos D1, etc.)
- Raspberry Pi (all models)
- Any microcontroller with UART serial communication
