DIYables Expansion Board for Arduino Nano Family

Key Features

• Grouped Pin Headers : Each Arduino Nano pin broken out with dedicated VCC and GND pins in the same group, eliminating need for separate power rails and simplifying sensor connections
• Stackable Design : Arduino Nano family boards plug directly on top, with all pins accessible via organized grouped pin headers below
• All Pins Broken Out : Every Arduino Nano pin accessible via convenient 3-pin groups (Signal + VCC + GND) for easy module and sensor wiring
• 5x I2C Expansion Pins : Multiple I2C ports allow connecting several I2C devices simultaneously without additional wiring or breadboards
• DC Barrel Jack : Convenient DC barrel jack connector accepts 6-20V external power supply for powering the Nano and connected peripherals
• Universal Nano Family Compatibility : Compatible with all Arduino Nano family boards including Nano, Nano R4, Nano 33 IoT, Nano RP2040 Connect, Nano 33 BLE Sense, Nano 33 BLE, Nano Every, and Nano ESP32
• Simplified Wiring : Each pin group provides signal, power, and ground together, reducing wiring complexity and minimizing connection errors
• No Breadboard Needed : Grouped pin design eliminates need for breadboards or power distribution boards for most sensor and module connections
• Perfect for Prototyping : Quick sensor connections and organized layout ideal for rapid prototyping, testing, and educational projects
• Power Distribution : VCC and GND available at every pin group ensures clean power distribution across all connected modules
• Organized Layout : Clear labeling and logical pin grouping makes project development faster and more intuitive
• Versatile Applications : Excellent for robotics, sensor networks, IoT devices, educational projects, rapid prototyping, and development platforms
